The SCMC 30 is the C-rail mounting option for the two large MSMC clamp sizes – MSMC 30-46 and MSMC 44-55 – and comes with the heavier M8 hexagon head screw those clamps need. It lets a large cable clamp be positioned anywhere along a rail and slid to final position before tightening, without drilling the mounting plate.

Features and Specifications

Suitable for: MSMC 30-46 and MSMC 44-55 cable clamps. Dimensions: 40 x 25 x 6.5 mm (L x W x H). Supplied with M8 hexagon head screw.

Application:

Drop the sliding nut into the C-rail slot, turn it to engage the lips, then fix the cable clamp through its central slotted hole with the supplied M8 screw. Rail mounting suits heavy feeds where clamp spacing may need adjusting during installation. Tighten the clamp screw connection to 3 Nm when clamping cable.

What's Included: One sliding nut and one M8 hexagon head screw. Sold individually; icotek supplies the SCMC range in packs of five.

Related products: MSMC 30-46 Set A and MSMC 44-55 Set A cable clamps, the CMC 30 coupler, and the SCMC 10 for the smaller clamp sizes.
