Coupler for MSMC 30-46 & 44-55 Cable Clamps | CMC 30

SKU
$1.25 ex. GST $1.38 inc. GST
In stock
50 in stock across 2 warehouses
  • Type Coupler
  • Series MSMC
  • Material Polyamide
  • Colour Black
  • Country of Origin DE

Coupler for MSMC 30-46 & 44-55 Cable Clamps | CMC 30

The CMC 30 joins the two large MSMC clamp sizes – MSMC 30-46 and MSMC 44-55 – into a continuous row, and it is also the coupler icotek specifies for connecting clamps of different clamping ranges to one another, so a run of mixed cable sizes can share one mounting line.

Features and Specifications

Suitable for: MSMC 30-46 and MSMC 44-55 cable clamps; also used to connect different MSMC clamping ranges. Dimensions: 50 x 20 x 15 mm (L x W x H).

Material:

Polyamide (PA), black

Application:

The coupler clips between the lower parts of two adjacent clamps, locking them together laterally. Any number of clamps can be lined up this way, and mixed clamping ranges can be brought onto the same line. It also serves as a mounting aid when working overhead. One coupler is already included in each MSMC Set A and Set B – order the CMC 30 separately when extending an existing row or bridging two sizes.

What's Included: One coupler. Sold individually; icotek supplies the CMC range in packs of ten.

Related products: MSMC 30-46 Set A and MSMC 44-55 Set A cable clamps, the SCMC 30 C-rail sliding nut, and the CMC 10 for the smaller clamp sizes.
