Remote I/O Module Connecting Plug

The Weidmüller UR20-PG0.35 is the plug-in connecting plug used to wire the high-density (HD) modules of the u-remote remote I/O system. It takes fine conductors from 0.14 to 0.35 mm² in PUSH IN terminals and is the field-wiring interface for HD modules such as the UR20-8DI-3W-HD, UR20-8DO-HD and UR20-4AI-16-HD, which have no fixed terminal block of their own.

• Type: UR20-PG0.35 connecting plug, u-remote system accessory
• Used with: u-remote HD modules — UR20-8DI-3W-HD, UR20-8DO-HD, UR20-4AI-16-HD
• Connection: PUSH IN
• Conductor cross-section: 0.14 to 0.35 mm² (AWG 26–22)
• Wiring schemes: 3- and 4-conductor
• Pack quantity: 8 plugs
• Weight: 2.33 g per plug
