Coupler for MSMC 10-22 & 20-32 Cable Clamps | CMC 10

SKU
$0.94 ex. GST $1.03 inc. GST
In stock
50 in stock across 2 warehouses
  • Type Coupler
  • Series MSMC
  • Material Polyamide
  • Colour Black
  • Country of Origin IT

Coupler for MSMC 10-22 & 20-32 Cable Clamps | CMC 10

The CMC 10 is the small coupler that turns individual MSMC clamps into a continuous row. It joins MSMC 10-22 and MSMC 20-32 clamps horizontally, so a bank of control and instrumentation cables can be clamped off a single mounting point rather than drilling for each clamp.

Features and Specifications

Suitable for: MSMC 10-22 and MSMC 20-32 cable clamps. Dimensions: 35 x 13.4 x 12 mm (L x W x H).

Material:

Polyamide (PA), black

Application:

The coupler clips between the lower parts of two adjacent clamps, locking them together laterally. Any number of clamps can be lined up this way. It also serves as a mounting aid when working overhead, holding the assembly in place while the screws are started. One coupler is already included in each MSMC Set A and Set B – order the CMC 10 separately when extending an existing row.

What's Included: One coupler. Sold individually; icotek supplies the CMC range in packs of ten.

Related products: MSMC 10-22 Set A and MSMC 20-32 Set A cable clamps, the SCMC 10 C-rail sliding nut, and the CMC 30 for the larger clamp sizes.
