SFP Module, Gigabit Ethernet, Singlemode, Duplex, 40KM Range - IE-SFP-1GE-SM-40

Weidmüller IE-SFP-1GE-SM-40 is a gigabit singlemode SFP transceiver for links of up to 40 km at 1,310 nm over an LC duplex connector. It has a 21 dB link budget and supports digital diagnostic monitoring, so optical power can be read back from the switch on long inter-site runs.

• Transmission speed: 1,000 Mbit/s
• Media and mode: Singlemode fibre-optic
• Wavelength: 1,310 nm typical (TX 1,280 ... 1,350 nm, RX 1,260 ... 1,610 nm)
• Maximum range: 40 km
• Connector: LC duplex
• Link budget: 21 dB
• Transmit power: -3 ... 3 dBm
• Receive power: -24 ... -3 dBm
• DDM: Supported (digital diagnostic monitoring)
• Supply voltage: 3.3 V, drawn from the host switch
• Operating temperature: -40 °C ... 85 °C
• Approvals: UL 62368-1 (certificate E230683), RoHS
• Warranty: 3 years
