Home » Cables» SCREENFLEX FR 110 VC4V-K Screened Control Cable 300/500V 5G1.5mm² Grey
SCREENFLEX FR 110 VC4V-K JZ 300/500V 5G1.5MM2 — Top Cable
SCREENFLEX FR 110 VC4V-K JZ 300/500V 5G1.5MM2 — Top Cable

Disclaimer: Images are for reference only. Refer to datasheets and drawings for accurate specifications.

Top Cable

SCREENFLEX FR 110 VC4V-K Screened Control Cable 300/500V 5G1.5mm² Grey

SKU
$5.13 ex. GST $5.64 inc. GST
Min. order: 10
Restocking
0 in stockUpdated 1 minute agoShipping & pickup →
  • Conductor Size 1.5
  • Conductor Count 5
  • Insulation PVC
Product Datasheet PDF

Top Cable SCREENFLEX FR 110 VC4V-K screened flexible control cable, 300/500V.

  • Class 5 flexible copper conductors
  • PVC insulation, green/yellow earth core
  • Aluminium-polyester tape with tinned copper braid screen for EMC protection
  • Grey flame-retardant PVC outer sheath
  • For signal and control circuits near drives and other noise sources

Sold per metre, cut to any length from 10 m.
