PROeco Switch-Mode Power Supply 72W 12V 6A

The Weidmüller PRO ECO 72W 12V 6A is a single-phase switch-mode power supply for TS 35 DIN rail, feeding a 12 V DC circuit at up to 6 A. PRO ECO is the compact economy family, so this is the unit to pick when a panel needs a plain 12 V rail for sensors, relays or a modem and there is no room or budget for a wider supply with boost and signalling.

• Output: 12 V DC ± 1 %, 6 A at 55 °C (4.5 A at 60 °C), adjustable 10-16 V
• Continuous power: 72 W
• Input: 85-264 V AC single phase, 47-63 Hz
• Efficiency: 85 %
• Connection: Screw terminals, 0.5-2.5 mm² flexible / 0.5-6 mm² rigid
• Mounting: TS 35 DIN rail
• Operating temperature: -25 °C to +70 °C
• Approvals: cULus E258476, RoHS, IP20, protection class I with earth connection
• Dimensions: 34 x 125 x 100 mm (W x H x D), 520 g
