PROeco Switch-Mode Power Supply 120W 12V 10A
Regular price
$105.82
ex. GST
$116.40
inc. GST
In stock
The Weidmüller PRO ECO 120W 12V 10A is a single-phase DIN rail switch-mode power supply that provides a regulated 12 V DC rail for control panels and equipment enclosures. The PRO ECO family is the compact economy tier, so it suits 12 V sensor, relay and communications loads where the boost reserve and communications of a PRO MAX or PRO TOP are not required.
- Output: 12 V DC ± 1 %, 10 A at 55 °C, adjustable 10-16 V
- Continuous power: 120 W
- Input: 85-264 V AC single phase, 47-63 Hz
- Efficiency: 87 %
- Operating temperature: -25 °C to 70 °C, derated to 2.5 A at 70 °C
- Connection: screw terminals, TS 35 DIN rail mounting
- Protection: short-circuit, overload and reverse voltage protection; IP20, protection class I with earth connection
- Parallel operation: up to 5 units
- Dimensions: 40 x 125 x 100 mm (W x H x D)
