IP68 Panel Mount Cable Connector 2-Pole Female Socket
Ask an expert!
- IP Rating
Standards & certifications
IP68Continuous immersion
The Weidmüller 2860640000 (RC F P2 M20 SP) is a 2-pole panel mount cable connector female socket with screw terminal connection, rated at 17.5A and 500V with IP68 ingress protection. Designed for front-mounting on enclosures, control cabinets, and machines. Provides a secure, waterproof cable entry point accessible from the field side without opening the enclosure. The M20 screw terminal connection accommodates conductor cross-sections from 0.5 to 4 mm² and cable diameters from 7 to 13 mm, ensuring secure and reliable termination. Features reverse polarity protection and PA 66 housing. Pairs with the Weidmüller 2860650000 male plug to form a complete panel mount connector system. Protective cap (2833850000) available separately to maintain IP68 rating when disconnected.
| Article Number | 2860640000 |
| Weidmüller Type | connector |
| Configuration | Panel Mount — Female Socket |
| Number of Poles | 2 |
| Connection Type | Screw connection |
| Rated Current | 17.5 A |
| Rated Voltage | 500 V |
| IP Rating | IP68 |
| Connection Thread | M20 |
| Cable Diameter | 7–13 mm |
| Conductor Cross-Section | 0.5–4 mm² |
| Housing Material | PA 66 |
| Operating Temperature | -40 °C to +85 °C |
| Reverse Polarity Protection | Yes |
| Approvals | cULus (E307231) · RoHS |
