IP68 Panel Mount Cable Connector 2-Pole Male Plug
Ask an expert!
The Weidmüller 2860650000 (RC M P2 M20 SP) is a 2-pole panel mount cable connector male plug with screw terminal connection, rated at 17.5A and 500V with IP68 ingress protection. Designed for front-mounting on enclosures, control cabinets, and machines. Provides a waterproof, field-mateable cable entry point. The panel mount design allows fixed installation on the enclosure wall and enables cable connection and disconnection from the field side without opening the enclosure. The M20 screw terminal connection accommodates conductor cross-sections from 0.5 to 4 mm², providing secure and vibration-resistant termination. Features reverse polarity protection and PA 66 housing. Pairs with the Weidmüller 2860640000 female socket to form a complete inline connector system. Protective cap (2820090000) available separately to maintain IP68 rating when disconnected.
| Article Number | 2860650000 |
| Weidmüller Type | connector |
| Configuration | Panel Mount — Male Plug |
| Number of Poles | 2 |
| Connection Type | Screw connection |
| Rated Current | 17.5 A |
| Rated Voltage | 500 V |
| IP Rating | IP68 |
| Connection Thread | M20 |
| Cable Diameter | 7–13 mm |
| Conductor Cross-Section | 0.5–4 mm² |
| Housing Material | PA 66 |
| Operating Temperature | -40 °C to +85 °C |
| Reverse Polarity Protection | Yes |
| Approvals | cULus (E307231) · RoHS |
