Ø40mm Emergency Stop 22mm IP65, Push & Twist Release

Ø40mm Emergency Stop, Push & Twist to Release

The LA1S100R is a Ø40mm red mushroom emergency stop operator with push-and-twist-to-release action. Sized for panel-front mounting on machinery and control stations where an unmistakable, deliberate reset is required before the circuit can be re-made.

Features and Specifications

Protection: IP65. Operating range -20°C to +60°C.

Standards (& Conformities): IEC 60947-1, IEC 60947-5-1, CE, RoHS.

Mounting:

Panel cut-out: Ø22.3mm ±0.2 (M22×1)
Panel thickness: 0.8–6 mm

Vibration resistance:

Mis-operation 5–55 Hz, single amplitude 0.5 mm. Durability 30 Hz, single amplitude 1.5 mm.

Contact blocks are ordered separately. This is an operator only and ships without contacts. A normally-closed contact is the correct choice for the stop circuit itself — LAA01 (1NC), or LAA02 (2NC) for dual-channel wiring. Normally-open blocks can also be fitted where the stop state needs to be signalled back to a PLC or indicator: LAA11 (1NO+1NC) gives you both in a single block, and further blocks can be stacked as required.

Materials:

PA66 button, PA66 cover and housing

Manufacturer: Telergón, S.A.U. — European-engineered, CE marked to the Low Voltage (2014/35/EU) and RoHS (2011/65/EU) Directives.

Note: Please choose product carefully. Product selection is the responsibility of the Purchaser. Refer to relevant Standards, project requirements and technical specifications to ensure that the product meets requirements.
