MEDIA INTERFACE MODULE, 4 X ST MULTIMODE FIBRE, 10/100 - IE-SWM-SL04-4ST

The Weidmüller IE-SWM-SL04-4ST is a plug-in media interface module with four 100BaseFX multimode fibre ports on ST-duplex connectors. It populates module slot M1, M2 or M3 of the SubstationLine modular managed switch chassis (IE-SW-SL26M / IE-SW-SL28M), which ship without media modules fitted, and suits retrofits into existing ST-terminated multimode plant.

• Ports: 4x 100BaseFX multimode
• Connector: ST-duplex
• Fibre mode: Multimode
• Transmission speed: Fast Ethernet, 100 Mbit/s
• Maximum range: 2 km (typical)
• Wavelength: 1,310 nm (typical)
• Link budget: 7.5 dB
• Transmit power: -23.5 dBm to -14 dBm
• Receive sensitivity: -31 dBm to 0 dBm
• Module slot: M1, M2 or M3
• Supply: Via the host Ethernet switch
• Operating temperature: -40 °C to 85 °C
• Humidity: 5 to 95 % (non-condensing)
• Dimensions (W x H x D): 99 mm x 40.7 mm x 107 mm
• Weight: 348 g
• Approvals: CE, RoHS compliant (exemption 7cI)
