MEDIA INTERFACE MODULE, 4 X SFP+ 10G, M4 SLOT - IE-SWM-SL04-4GESFP+

SKU
$1,744.75 ex. GST $1,919.23 inc. GST
Restocking
Stock on hand
NSW WarehouseAuburn, NSW 2144
0 in stock
QLD WarehouseBells Creek, QLD 4551
0 in stock
VIC WarehouseEpping, VIC 3076
0 in stock
Updated just now
Shipping & pickup →

The Weidmüller IE-SWM-SL04-4GESFP+ is a plug-in media interface module with four combined SFP/SFP+ slots for Gigabit or 10-Gigabit Ethernet. It fits module slot M4 of the SubstationLine modular managed switch chassis (IE-SW-SL26M / IE-SW-SL28M), which ship without media modules fitted, and provides four high-speed fibre uplinks from a single slot.

  • Ports: 4x 1000BaseSFP / 10GBaseSFP+ slot
  • Connector: SFP/SFP+ cage; transceivers ordered separately
  • Transmission speed: Gigabit Ethernet / 10-Gigabit Ethernet
  • Module slot: M4
  • Supply: Via the host Ethernet switch
  • Operating temperature: -20 °C to 60 °C
  • Storage temperature: -40 °C to 85 °C
  • Dimensions (W x H x D): 99 mm x 40.7 mm x 136 mm
  • Weight: 348 g
  • MTBF: 1,871,812 h (Telcordia SR-332)
  • Approvals: cULus (UL 61010-1, UL 61010-2-201), certificate E141197; RoHS compliant (exemption 7cI)
