IP68 Inline Cable Connector 3-Pole Female Socket, Push-In Terminals
Regular price
$24.03
ex. GST
$26.43
inc. GST
Out of stock
Contact us for lead time
0 in stockContact us for lead time →
- Material
- IP Rating
- Voltage
- Current
- Poles
- Conductor Size
Standards & certifications
IP68Continuous immersion
Weidmüller RC F P3 C SP 3-pole female socket, rated 17.5 A / 500 V and IP68 when mated. Field-wireable with PUSH IN terminals (press the actuator, insert the wire, no tools) for 0.25–1.5 mm² wires and cable diameters 7–13 mm. Joins two cables in the field, or mates with the matching M20 panel mount connector. Reverse polarity protected.
Parts needed for a complete connection
- Mating connector: IP68 Inline Cable Connector 3-Pole Male Plug (2992960000)
- Protective cap (keeps IP68 when unplugged): Protective Cap for IP68 Female Plug (2833850000)
Specifications
| Weidmüller type | RC F P3 C SP |
|---|---|
| Configuration | Inline — female socket |
| Poles | 3 |
| Wire termination | PUSH IN with actuator |
| Rated current / voltage | 17.5 A / 500 V |
| Wire size | 0.25–1.5 mm² |
| Cable diameter | 7–13 mm |
| Protection | IP68 when mated |
| Housing material | PA 66 |
| Operating temperature | -40 °C to 60 °C |
| Approvals | RoHS |
