Home » Enclosures» Fibox ARCA Polycarbonate Enclosure 800H x 600W x 300D IP66 with 2 Quarter Turn Locks + Window, Including Mounting Plate
Fibox ARCA Polycarbonate Enclosure 800H x 600W x 300D IP66 with 2 Quarter Turn Locks + Window, Including Mounting Plate —
Fibox ARCA Polycarbonate Enclosure 800H x 600W x 300D IP66 with 2 Quarter Turn Locks + Window, Including Mounting Plate —

Disclaimer: Images are for reference only. Refer to datasheets and drawings for accurate specifications.

FIBOX

Fibox ARCA Polycarbonate Enclosure 800H x 600W x 300D IP66 with 2 Quarter Turn Locks + Window, Including Mounting Plate

SKU
$1,121.24 ex. GST $1,233.36 inc. GST
In stock
5 in stock across 3 warehouses
Free Shipping

Ask an expert!

Chat Email 1300876722
  • Height (mm) 800
  • Width (mm) 600
  • Depth (mm) 300
  • Material Polycarbonate
  • Colour Grey
  • IP Rating IP66
  • Lock Type 3mm Double Bit 2-Point
  • Door Type Single Door
  • Transparent Door
  • Flammability Rating UL 94 5VA

Standards & certifications

IP66Dust-tight · powerful jets IK10Impact rated NEMAUS enclosure rating IEC/EN 62208 · 614391 · 614394 Tested standards
Product Datasheet PDF Dimensional Drawing PDF CAD File STEP Declaration of Conformity PDF

The FIBOX ARCA-806030W is a polycarbonate wall-mount enclosure with a transparent window lid, rated IP66 and IK10. The window panel allows visual inspection of internal components without opening the enclosure — ideal for indicator lamps, displays, and status monitoring in harsh environments.

Constructed from high-impact, UV-stabilised polycarbonate with a polyurethane FIP foam-in-place gasket for a reliable, long-life seal. Supplied with a stainless steel grounding stud, internal mounting plate, and two 3mm double-bit quarter-turn locks.

  • IP Rating: IP66
  • IK Rating: IK10
  • Material: Polycarbonate
  • Colour: Grey (RAL 7035)
  • Seal: Polyurethane FIP
  • Lock: 3mm Double Bit 2-Point
  • Dimensions: 800H × 600W × 300D mm
  • Operating Temp: -40°C to 80°C
  • Flammability: UL 94 5VA
  • Country of Origin: Finland

Certifications: IP66 · IK10 · NEMA. Standards: IEC 62208 · IEC 61439-1 · IEC 61439-4.

TROAPC's standard warranty covers all products. A 5-year warranty applies to applicable IP Enclosures products. Refer to Refunds & Returns for more information.
