MEDIA INTERFACE MODULE, 4 X SC SINGLEMODE FIBRE, 10/100 - IE-SWM-SL04-4SCS

The Weidmüller IE-SWM-SL04-4SCS is a plug-in media interface module with four 100BaseFX singlemode fibre ports on SC-duplex connectors. It populates module slot M1, M2 or M3 of the SubstationLine modular managed switch chassis (IE-SW-SL26M / IE-SW-SL28M), which ship without media modules fitted, and carries Fast Ethernet over long-haul spans of up to 30 km.

• Ports: 4x 100BaseFX singlemode
• Connector: SC-duplex
• Fibre mode: Singlemode
• Transmission speed: Fast Ethernet, 100 Mbit/s
• Maximum range: 30 km (typical)
• Wavelength: 1,310 nm (typical)
• Link budget: 19 dB
• Transmit power: -15 dBm to -8 dBm
• Receive sensitivity: -34 dBm to 0 dBm
• Module slot: M1, M2 or M3
• Supply: Via the host Ethernet switch
• Operating temperature: -40 °C to 85 °C
• Housing: Metal
• Dimensions (W x H x D): 99 mm x 40.7 mm x 107 mm
• Weight: 348 g
• Approvals: CE, RoHS compliant (exemption 7cI)
