LB63HW 3P+N C25 30mA A-TYPE | RCBO 25A 3P+N 10kA C Curve
Images are for reference only. Refer to datasheets and drawings for accurate specifications.
Details
LB63HW 3P+N C25 30mA A-TYPE | RCBO 25A 3P+N 10kA C Curve
The LS Electric LB63HW 25A 3P+N RCBO offers dependable overcurrent and earth leakage protection in a compact, DIN rail-mountable format. Rated at 10kA with a C curve tripping characteristic and 30mA A-Type sensitivity, it's built for 400/415VAC systems in industrial, commercial, and residential environments. Compliant with IEC/EN 61009-1 and approved by CE, CB, and UKCA standards, this RCBO supports a wide range of applications where both overcurrent and residual current protection are critical. Features include electronic trip mechanism, IP20 rating, -25°C to +60°C operation, and support for up to 25mm² cables.
