304 Stainless Steel Electrical Enclosure 500H x 500W x 300D IP66

SKU
In stock
Stock on hand
NSW WarehouseAuburn, NSW 2144
6 in stock
QLD WarehouseBells Creek, QLD 4551
0 in stock
VIC WarehouseEpping, VIC 3076
0 in stock
Updated 1 minute ago
Shipping & pickup →
$836.73 ex. GST $920.40 inc. GST
Free Shipping

Ask an expert!

Chat Email 1300876722
  • Height (mm) 500
  • Width (mm) 500
  • Depth (mm) 300
  • Material Stainless Steel 304
  • IP Rating IP66
  • Door Type Single Door
  • Seal Type Polyurethane FIP
  • Lock Type 8mm Square Drive Quarter Turn
  • Operating Temperature −40°C to +80°C
  • Standards
    • IEC 62208
    • IEC/EN/AS60529
    • IEC/EN 61439
  • Certifications
    • IP66
    • IK10
    • CE
    • UKCA
    • UL
    • NEMA 4X
    • RoHS
304 Stainless Steel Electrical Enclosure 500H x 500W x 300D IP66




Note: Please choose product carefully. Product selection is the responsibility of the 'Purchaser'. Refer to relevant Standards, project requirements and technical specifications to ensure that the product meets requirements. For more information on product selection, refer to this link.

Your product is covered by a 12 month Warranty or more if you opted for the extended warranty. Make sure you register your product.
