M610 Label Printer with Bluetooth Kit
Images are for reference only. Refer to datasheets and drawings for accurate specifications.
Details
M610 Bluetooth Printer Kit
Same great printer, only better
The BMP61 Label Printer has been updated to the M610 — see what’s improved:
Faster print speeds, enabling printing up to 2 inches per second
Upgraded from NiMH to Li-ION battery pack — lighter and faster — same as on AC
Now print barcode fonts >10pt, 2D barcodes, ISO 7010 symbols and store files on printer
Added durability to withstand up to 6 foot drop and meets MIL-STD-810G vibration testing
Design and print labels using a keypad, mobile app or desktop software including text, barcodes, shapes and images
- 50.8mm per second print speed
- Enhanced Gen3 Li-ION battery
- Store and import data files from USB thumb drive
- Import and save files, lists and graphics
- Design and print labels using a keypad, mobile app or desktop software
- Prints text, barcodes, shapes and images
- Wider (-18 to 46 C) operating temperature range
Overview
What's In the box
- Brady M610 Label Printer with Bluetooth
- M610 Hard Case
- Li-ION Battery Pack
- AC adapter with power cord
- USB cable
- Black Ribbon
- Self Lam Label Roll (M6-11-427)
- Quick Start Guide
- BWS Basic Suite
- USB Flash Drive
| Unit of Measure | Each |
|---|---|
| Height (mm) | 328 |
| Width (mm) | 107 |
| Depth (mm) | 106 |
| Size | 328 mm H x 107 mm W x 106 mm D |
| Connectivity Type | Bluetooth |
| Power Supply Options | Li-ion Rechargeable Battery |
| Power Source Voltage | 110 - 240 V |
| Memory Capacity (MB) | 512 MB RAM, 256 MB Flash |
| Cutter Type | Manual |
| Keyboard Style | QWERTY |
| PC Compatibility | PC Connect and Stand Alone |
| Software Compatibility | Brady Workstation, Brady Mobile Apps |
| Model | M610 |
| Print Technology | Thermal Transfer |
| Labels Per Day | 750 |
| Maximum Print Width (mm) | 50 |
| Continuous vs Die Cut | Continuous and Die-cut |
| Print Speed (mm/sec) | 50mm/s |
| Print Resolution (dpi) | 300 |
| Compatible Media | BM-, BMC-, M6-, M6C- |
| Barcodes | Code 39, Code 128, Yes - With Software |
| Printer Barcode Type | Code 128, Code 39, EAN-13, Interleaved 2 of 5, More through Brady WorkStation, UPC-A, UPC-E |
| Number of Symbols | 480 |
| Font Types Available | Brady Alpine, Brady Fixed Width |
| Text Sizes | 4 - 170 pt |
