2 Fan Tray for 19" Data Rack
Images are for reference only. Refer to datasheets and drawings for accurate specifications.
Details
2 Fan Tray for 19" Data Rack
High quality Italian 2 fan tray for 19" data racks.
| Features | Unit | IP-RACKFAN2 |
|---|---|---|
| Air flow rate (free blow) m³/h 300(360) | ||
| Power supply | V/Hz | 230/50-60 |
| Dimensions HxWxD | mm | 482x44x208 |
| Power consumption | W | 36(34) |
| Current consumption | A | 0.26(0.22) |
| Overcurrent protection | – | impedance |
| Electric connection | – | 3-pole terminal 2.5 mm² |
| Duty cycle | – | 100% |
| Operating temperature | °C | -10/+70 |
| Protection degree/class | – | IP30/Class I |
| Noise level | dB(A) | 51(52) |
| Flow direction | – | bottom to top |
| Bearing | – | ball |
| Service life (at 40°C) | hr | 50.000 |
| Material | – | PC-ABS UL94V-0 Color RAL7035 |
| Weight (with packaging) | kg | 2.10(2.30) |
| Package dimensions | mm | 510x220x65 |
| Mounting | – | Screws |
| Conformity/Approvals | – | CE |
